The speed of the high speed benchtop refrigerated centrifuge can reach ≥ 10,000 rpm, it is composed of a body shell, a centrifuge chamber, a rotor, a refrigerating device and a control circuit. Microcomputer control, DC brushless motor, LED/LCD display speed and time, with refrigeration system, is special equipment for rapid separation of mixed liquids. Angle rotors used in high-speed refrigerated centrifuges are mostly made of titanium alloy/aluminum alloy. Various customized rotors are available. The machine is easy to operate and has a fast cooling speed.
- Carbon-free brushless frequency conversion motor to adjust the speed; maintenance-free, high torque, fast lifting speed.
- Microcomputer processor control, blue backlight LCD / LED screen display speed, centrifugal force operating parameters and RCF value.
- Fluorine-free compressor unit, double circulation refrigeration, strong heat and cold exchange ability, and high temperature control precision.
- Unique design of spring cone sleeve is used to connect rotor and main shaft,loading and unloading of the rotor is quick and simple.
- 10 sets of programs can be stored and recalled, and 10 kinds of lifting speeds are available for selection.
- Door cover adopt independent motor servo, reduce operator labor intensity, automatic protection for over-speed and over-temperature, unbalanced protection.
- Body is made of high-quality steel structure and three-stage vibration reduction to ensure safety and the best centrifugal effect.
- Various customized rotors are available.
The benchtop high-speed refrigerated centrifuge is suitable for experiments with small separation volume, high centrifugation requirements, and low temperature, such as: collecting microorganisms, cell debris, cells, large organelles, sulfuric acid precipitates, and immunoprecipitates Etc., widely used in radioimmunoassay, medical laboratory/laboratory, biochemistry, scientific research laboratories, etc.
| Model | Max Speed | Max RCF | Max Capacity | Speed Accuracy | Timer Range | Temp Range | Temp Accuracy | Display | Motor | Power | Full Noise |
| KT-TGL30M KT-TGL30MR | 30000rpm | 65800 xg | 4*100ml | ± 10rpm | 1-99m/9h59min | -20°C ~ +40°C | 土1°C | LED/LCD | AC inverter motor | AC 220V 50HZ 10A，950W | ≤62db |
| KT-TGL20M KT-TGL20MR | 20000rpm | 28948xg | 6*100ml | ± 10rpm | 1-99m/9h59min | -20°C ~ +40°C | 土1°C | LED/LCD | AC inverter motor | AC 220V 50HZ 10A，1200w | ≤62db |
| KT-TGL20F KT-TGL20FR | 22000rpm | 33660 xg | 6* 100ml | ± 10rpm | 1-99m/9h59min | -20°C 〜+40°C | 土1°C | LED/LCD | AC inverter motor | AC 220V 50HZ 10A,1100W | ≤62db |
| KT-TGL20E KT-TGL20ER | 21000rpm | 30930 xg | 6*100ml | ± 10rpm | 1-99m/9h59min | -20°C ~ +40°C | 土1°C | LED/LCD | AC inverter motor | AC 220V 50HZ 10A，1100W | ≤62db |
| KT-TGL18M KT-TGL18MR | 18000rpm | 23566xg | 6*100ml | ± 10rpm | 1-99m/9h59min | -20°C 〜+40°C | 土1°C | LED/LCD | AC brushless motor | AC 220V 50HZ 10A，1000W | ≤62db |
| KT-TGL18E KT-TGL18ER | 18500rpm | 23810xg | 6*100ml | ± 10rpm | 1-99m/9h59min | -20°C 〜+40°C | 土1°C | LED/LCD | AC brushless motor | AC 220V 50HZ 10A，1100W | ≤62db |
| KT-TGL16M KT-TGL16MR | 16500rpm | 20653xg | 4*100ml | ± 10rpm | 1-99m/9h59min | -20°C 〜+40°C | 土1°C | LED/LCD | Brushless AC frequency conversion | AC 220V 50HZ 10A，1100W | ≤65db |
| KT-TGL16W KT-TGL16WR | 16000rpm | 17846xg | 10*5ml | ± 10rpm | 1-99m/9h59min | -20°C 〜+40°C | 土1°C | LED/LCD | Brushless AC frequency conversion | AC 220V 50HZ 10A，880W | ≤60dB(A) |
